For CAD workflows, a reliable and high-capacity NAS storage system is essential to manage large files and ensure smooth collaboration. The Synology DS1825+ stands out for its balance of performance and expandability, making it ideal for demanding projects. The QNAP TS-873A-8G offers powerful features suited for intensive CAD tasks, while the Terramaster U8-500 provides a budget-friendly, diskless option for custom setups. Each of these options balances capacity, speed, and ease of use differently, presenting tradeoffs between cost and performance. Keep reading for a detailed comparison to find the best fit for your CAD workflows.
Prime made for students and young adults
- Fast, free delivery for dorm and study essentials
- Prime Video and Amazon Music included
- Member-only deals
Key Takeaways
- The best overall pick balances performance, expandability, and ease of use, with the Synology DS1825+ leading due to its reliability and scalable design.
- QNAP models often offer faster network interfaces and more powerful hardware, making them ideal for high-demand CAD environments.
- Diskless solutions like the Terramaster U8-500 provide flexibility for custom storage configurations but require more setup effort.
- Choosing between rackmount and desktop form factors depends on available space and deployment preferences, influencing your overall workflow integration.
- Price points vary widely; investing in higher-end models generally yields better long-term performance but may be overkill for smaller teams or less intensive workflows.
| Synology 8-Bay RackStation RS1221+ (Diskless) |  | Best Overall for High-Performance Multi-User Environments | Number of Bays: 8 | Performance: Up to 2,315 MB/s read, 1,147 MB/s write | Depth: 298 mm | VIEW ON AMAZON | See Our Full Breakdown |
| Synology DS1825+ Enterprise NAS Storage – 8-Bay, 360TB Capacity, 25GbE Speed, Mission-Critical Reliability |  | Best for Scalable, Enterprise-Grade Storage in CAD Workflows | Model Number: DS1825+ | Number of Bays: 8 | Maximum Storage Capacity: 360TB | VIEW ON AMAZON | See Our Full Breakdown |
| Asustor Lockerstor 8 AS6508T 8-Bay NAS Network Storage Enclosure |  | Best for High-Speed Network Connectivity and Extensive Data Storage | Processor: Intel Atom C3538 Quad Core 2.1GHz | RAM: 8GB DDR4 | Drive Bays: 8 x 3.5 inch SATA | VIEW ON AMAZON | See Our Full Breakdown |
| QNAP TS-855X-8G-US 8-Bay NAS |  | Best for Expandable Performance with PCIe Flexibility | Processor: Intel Atom C5125 8-core 2.8GHz | RAM: 8GB DDR4 (up to 128GB) | Network Ports: 1 x 10Gbase-T, 2 x 2.5GbE | VIEW ON AMAZON | See Our Full Breakdown |
| QNAP TS-873AeU-4G-US 8-Bay Rackmount NAS |  | Best for Power and Flexibility in Rackmount Form Factor | Processor: AMD Ryzen Embedded V1500B 4-core/8-thread 2.2 GHz | RAM: 4GB DDR4 (up to 64GB) | Number of Bays: 8 | VIEW ON AMAZON | See Our Full Breakdown |
| QNAP TS-832PX-4G 8-Bay NAS |  | Best Overall for Balance of Performance and Expandability | Processor: AnnapurnaLabs Alpine AL324 ARM Cortex-A57 quad-core 1.7GHz | RAM: 4 GB DDR4 (expandable to 16 GB) | Drive Bays: 8 x 3.5-inch SATA 6Gb/s, 3Gb/s | VIEW ON AMAZON | See Our Full Breakdown |
| QNAP TS-873A-8G 8 Bay NAS |  | Best for High-Performance and Advanced Storage Optimization | Processor: AMD Ryzen V1500B quad-core 2.2 GHz | RAM: 8GB DDR4 (max 64GB) | Network Ports: 2 x 2.5 Gigabit Ethernet | VIEW ON AMAZON | See Our Full Breakdown |
| TERRAMASTER U8-500 Plus NAS 8-Bay Intel Core i7 1255U, 16GB DDR5 |  | Best for Heavy-Duty Performance and Large Capacity Needs | Processor: Intel Core i7-1255U | Cores: 10 cores | Memory: 16GB DDR5 | VIEW ON AMAZON | See Our Full Breakdown |
| top rated 8 bay nas storage system for cad workflow | Processor | RAM | Network Ports |
|---|---|---|---|
| Synology 8-Bay RackStation RS1 | — | — | — |
| Synology DS1825+ Enterprise NA | — | — | — |
| Asustor Lockerstor 8 AS6508T 8 | Intel Atom C3538 Quad Core 2.1GHz | 8GB DDR4 | — |
| QNAP TS-855X-8G-US 8-Bay NAS | Intel Atom C5125 8-core 2.8GHz | 8GB DDR4 (up to 128GB) | 1 x 10Gbase-T, 2 x 2.5GbE |
| QNAP TS-873AeU-4G-US 8-Bay Rac | AMD Ryzen Embedded V1500B 4-core/8-thread 2.2 GHz | 4GB DDR4 (up to 64GB) | Dual 2.5GbE |
| QNAP TS-832PX-4G 8-Bay NAS | AnnapurnaLabs Alpine AL324 ARM Cortex-A57 quad-core 1.7GHz | 4 GB DDR4 (expandable to 16 GB) | — |
| QNAP TS-873A-8G 8 Bay NAS | AMD Ryzen V1500B quad-core 2.2 GHz | 8GB DDR4 (max 64GB) | 2 x 2.5 Gigabit Ethernet |
| TERRAMASTER U8-500 Plus NAS 8- | Intel Core i7-1255U | — | 2 x 10GbE |
More Details on Our Top Picks
Synology 8-Bay RackStation RS1221+ (Diskless)
The Synology RS1221+ stands out for its high data transfer speeds, making it ideal for multi-user CAD workflows where rapid access to large files is essential. Compared to the QNAP TS-855X, this model emphasizes speed and reliability with up to 2,315 MB/s read and 1,147 MB/s write, ensuring smooth collaboration. Its compact design allows flexible placement even in space-constrained offices. However, being diskless means you’ll need to invest in drives separately, which could add to the initial cost. Its high availability clustering supports mission-critical uptime, but the limited hardware details may challenge less tech-savvy users. If maximum performance in a compact form is your priority, this NAS is a top contender.
Pros:- Exceptional data transfer speeds suitable for intensive multi-user workflows
- Compact design with flexible placement options
- Supports high availability clustering for maximum uptime
Cons:- Requires separate purchase of drives, increasing initial investment
- Limited hardware specifications details may complicate setup
Best for: IT managers in multi-user CAD environments needing fast, reliable access with high uptime
Not ideal for: Small teams or freelancers who require an all-in-one, ready-to-use solution without additional drive costs
- Number of Bays:8
- Performance:Up to 2,315 MB/s read, 1,147 MB/s write
- Depth:298 mm
- Network Compatibility:PCIe SFP+ or RJ-45 network card
- Configuration:Supports high availability cluster
Our verdict“This NAS is best suited for teams demanding high performance and uptime in space-constrained environments.”
Synology DS1825+ Enterprise NAS Storage – 8-Bay, 360TB Capacity, 25GbE Speed, Mission-Critical Reliability
The Synology DS1825+ is tailored for enterprise environments requiring large-scale, scalable storage solutions. It offers up to 360TB with expansion options, which far exceeds typical CAD project needs, making it perfect for large teams or institutions. Its 25GbE networking provides ultra-fast data transfer, outperforming more modest options like the Asustor Lockerstor 8. While its setup can be complex and may demand technical expertise, this complexity is offset by its robust data protection features, clustering, and failover capabilities. The larger, bulkier design might be less suited for small offices, but for mission-critical CAD workflows with massive storage demands, this model delivers unmatched scalability and performance.
Pros:- Massive expandable storage capacity up to 360TB
- High-speed 25GbE network for demanding workflows
- Enterprise-grade data protection with clustering and failover
Cons:- Setup may be complex and require technical expertise
- Premium price point may be prohibitive for smaller budgets
- Bulkier form factor limits placement options
Best for: Large engineering firms or institutions managing extensive CAD datasets and requiring high availability
Not ideal for: Small offices or individual freelancers with limited space or lower storage needs
- Model Number:DS1825+
- Number of Bays:8
- Maximum Storage Capacity:360TB
- Network Speed:25GbE
- Warranty:3 years
- Supported Protocols:Data sharing, synchronization, backup, surveillance
Our verdict“This enterprise NAS excels in large-scale, mission-critical CAD environments where scalability and uptime are paramount.”
Asustor Lockerstor 8 AS6508T 8-Bay NAS Network Storage Enclosure
The Asustor Lockerstor 8 offers a compelling balance of high-speed networking and solid hardware for CAD workflows that demand quick file transfers. Its dual 10GbE ports outperform the Synology RS1221+ in raw network speed, making it a strong choice for teams working with large files. With support for up to 8 drives and a quad-core processor, it provides good performance, but the absence of included drives and limited software info could pose hurdles for less experienced users. Compared with the QNAP TS-855X, it emphasizes networking speed but may lack some of the expandability options. This pick makes sense for users who prioritize network throughput and extensive storage in a flexible, hardware-rich package.
Pros:- Dual 10GbE network ports for ultra-fast data transfer
- Supports up to 8 drives for extensive storage needs
- Quad-core processor ensures reliable performance
Cons:- No included drives, adding to total cost
- Setup can be complex for users unfamiliar with NAS configurations
- Limited details on software features could hinder ease of use
Best for: Medium-to-large CAD teams needing fast data access and robust hardware for network-intensive tasks
Not ideal for: Beginners or small offices seeking an all-in-one simple solution without additional setup complexity
- Processor:Intel Atom C3538 Quad Core 2.1GHz
- RAM:8GB DDR4
- Drive Bays:8 x 3.5 inch SATA
- Network Interfaces:Two 10GbE, two 2.5GbE
Our verdict“This NAS is aimed at users who need high network performance combined with extensive storage capacity for demanding CAD workflows.”
QNAP TS-855X-8G-US 8-Bay NAS
The QNAP TS-855X-8G is notable for its high-performance processor and flexible expansion options, making it suitable for CAD environments needing rapid data transfers and future upgrades. Its 8-core 2.8GHz Intel Atom C5125 and up to 128GB RAM support heavy multitasking. The dual M.2 NVMe slots facilitate caching, visibly improving workflow efficiency over models like the Synology RS1221+. However, the setup can be daunting for beginners, especially with its advanced features and multiple expansion options. The price reflects its premium capabilities, which may be unnecessary for smaller teams. For those who want a powerful, expandable NAS that can adapt as their CAD needs grow, this model offers a compelling mix of speed and flexibility.
Pros:- High-speed 10G network connectivity for rapid workflows
- Expandable RAM up to 128GB for intensive multitasking
- Dual M.2 NVMe slots for caching or additional SSD storage
- Multiple PCIe slots for expansion
Cons:- Complex setup requiring technical knowledge
- Higher price point for advanced features
Best for: Tech-savvy CAD teams needing high performance and extensive expandability
Not ideal for: Less experienced users or small offices that prefer straightforward, plug-and-play solutions
- Processor:Intel Atom C5125 8-core 2.8GHz
- RAM:8GB DDR4 (up to 128GB)
- Network Ports:1 x 10Gbase-T, 2 x 2.5GbE
- SSD Slots:2 x M.2 PCIe Gen 3 x4
- Expansion Slots:2 x PCIe Gen 3 x4
Our verdict“This NAS is best suited for power users who require maximum performance, expandability, and future-proofing for CAD workflows.”
QNAP TS-873AeU-4G-US 8-Bay Rackmount NAS
The QNAP TS-873AeU-4G offers a robust AMD Ryzen embedded processor, making it suitable for complex CAD workflows that demand high processing power. Its rackmount design provides enterprise-grade features while maintaining manageable size. With support for up to 64GB of RAM and dual 2.5GbE ports, it’s optimized for fast file sharing and large data transfers. Compared to the Synology DS1825+, this model emphasizes raw processing ability and rackmount convenience but might be overwhelming for those unfamiliar with advanced NAS configurations. The PCIe slot allows for significant customization, yet the initial setup can be complex for beginners. This NAS is well-suited for professional CAD teams seeking a powerful, expandable rackmount solution.
Pros:- Powerful AMD Ryzen V1500B processor for demanding tasks
- Expandable RAM up to 64GB
- Multiple USB and high-speed network ports
- PCIe slot for extensive customization
Cons:- Setup complexity may deter beginners
- Price may be high for smaller teams or casual users
Best for: Professional CAD teams needing high processing power and rackmount flexibility
Not ideal for: Small offices or freelancers seeking ready-to-use, simple storage solutions
- Processor:AMD Ryzen Embedded V1500B 4-core/8-thread 2.2 GHz
- RAM:4GB DDR4 (up to 64GB)
- Number of Bays:8
- Network Ports:Dual 2.5GbE
- PCIe Slots:1 x PCIe Gen 3 x8
Our verdict“This rackmount NAS is ideal for professional CAD environments requiring powerful hardware and flexible expansion options.”
QNAP TS-832PX-4G 8-Bay NAS
The QNAP TS-832PX-4G stands out for providing a solid balance between high-speed connectivity and user flexibility, making it an ideal choice for those managing complex CAD workflows. Its 10GbE ports enable fast data transfers crucial for large file handling, outperforming models like the Terramaster U8-500 Plus in network speed. However, being diskless, it requires additional investment in drives, and its setup can challenge less experienced users. Compared to the QNAP TS-873A-8G, it offers fewer expansion options but remains easier to configure for smaller teams. It’s best suited for mid-sized firms needing reliable, scalable storage without the premium cost of high-end processors or extensive internal upgrades.
Pros:- High-speed 10GbE network connectivity facilitates rapid large-file transfers
- Expandable RAM up to 16 GB improves performance for intensive workflows
- 8-bay capacity allows for significant storage scalability
Cons:- Diskless setup incurs extra cost and delayed deployment
- Complex configuration process can intimidate beginners
Best for: Small to medium CAD teams demanding high-speed network access and expandable storage.
Not ideal for: Home users or small startups with limited technical skills or minimal storage needs.
- Processor:AnnapurnaLabs Alpine AL324 ARM Cortex-A57 quad-core 1.7GHz
- RAM:4 GB DDR4 (expandable to 16 GB)
- Drive Bays:8 x 3.5-inch SATA 6Gb/s, 3Gb/s
- Ethernet Ports:2 x 2.5 Gigabit, 2 x 10 Gigabit
- Form Factor:Rackmount
- Maximum Storage:N/A (diskless)
Our verdict“This NAS is perfect for teams needing a balanced mix of speed, expandability, and straightforward network performance.”
QNAP TS-873A-8G 8 Bay NAS
The QNAP TS-873A-8G offers a compelling upgrade over entry-level options by integrating an AMD Ryzen V1500B processor, delivering significant performance boosts for demanding CAD workflows. Its dual 2.5GbE ports and PCIe slots enable flexible networking and fast connectivity, surpassing the QNAP TS-832PX-4G in raw processing power and expandability. This model’s support for SSD caching and Qtier technology specifically targets intensive data access and storage optimization, making it ideal for large projects. The setup complexity and higher price point, however, might deter smaller teams or less technical users. If your CAD environment benefits from high-performance computing and advanced storage features, this model justifies the investment, although it may be overkill for simpler setups.
Pros:- Powerful AMD Ryzen V1500B processor handles intensive CAD workflows smoothly
- Supports SSD caching and Qtier technology for optimized performance
- Multiple network options including dual 2.5GbE ports and PCIe slots for expansion
- Expandable RAM up to 64GB increases multitasking capacity
Cons:- High cost may be prohibitive for smaller teams or budget-conscious users
- Setup requires technical knowledge due to complex configuration options
- Large physical footprint may not fit in compact spaces
Best for: Design firms or engineering teams requiring maximum processing power and advanced storage features.
Not ideal for: Small offices or hobbyist users with basic storage needs and limited technical expertise.
- Processor:AMD Ryzen V1500B quad-core 2.2 GHz
- RAM:8GB DDR4 (max 64GB)
- Network Ports:2 x 2.5 Gigabit Ethernet
- Storage Slots:8 x 3.5-inch SATA
- Supported SSDs:2 x M.2 NVMe SSD
- Operating Systems:QTS and QuTS hero
Our verdict“This NAS excels for high-end CAD users needing maximum performance and flexible storage configurations at a premium price.”
TERRAMASTER U8-500 Plus NAS 8-Bay Intel Core i7 1255U, 16GB DDR5
The TERRAMASTER U8-500 Plus stands out for its robust Intel Core i7-1255U processor and 16GB DDR5 RAM, making it a top choice for intensive CAD workflows that demand both speed and massive storage. Its 192TB maximum capacity and dual 10GbE ports support large-scale projects and fast network throughput, outperforming the other models when it comes to raw processing and storage volume. Designed in a 2U rack-mount form factor, it’s best suited for server rooms or dedicated storage closets. Its setup is more involved, requiring some technical expertise, and it does not come with drives, adding to the initial cost. This model is ideal for large teams or firms with extensive data management needs, but overkill for smaller or less demanding environments.
Pros:- Powerful Intel Core i7 processor handles multi-user CAD environments efficiently
- Supports up to 192TB of storage, ideal for large project archives
- Dual 10GbE ports deliver rapid data transfer speeds
- Flexible RAID configurations for tailored data protection
Cons:- Requires advanced technical setup and configuration skills
- No drives included, increasing overall deployment costs
- Overbuilt for small-scale or casual CAD use
Best for: Large enterprises or data centers managing massive CAD files and demanding storage workloads.
Not ideal for: Small business offices or home users with limited budgets or simpler storage requirements.
- Processor:Intel Core i7-1255U
- Cores:10 cores
- Memory:16GB DDR5
- Drive Bays:8
- Maximum Storage Capacity:192TB
- Network Ports:2 x 10GbE
Our verdict“This NAS is suited for large-scale CAD operations demanding maximum storage and processing power with high-speed networking.”
How We Picked
The products in this roundup were selected based on their capacity, performance, expandability, build quality, and reputation within CAD and professional workflows. We prioritized models with reliable hardware, fast networking options (like 10GbE or higher), and flexible RAID configurations to handle large CAD files efficiently. Cost and ease of setup were also considered, ensuring options are accessible for varying budgets and technical expertise. The ranking reflects a balance between these factors, emphasizing models that excel in real-world CAD environments while considering long-term value and support.| top rated 8 bay nas storage system for cad workflow | Processor |
|---|---|
| Synology 8-Bay RackStation RS1 | — |
| Synology DS1825+ Enterprise NA | — |
| Asustor Lockerstor 8 AS6508T 8 | Intel Atom C3538 Quad Core 2.1GHz |
| QNAP TS-855X-8G-US 8-Bay NAS | Intel Atom C5125 8-core 2.8GHz |
| QNAP TS-873AeU-4G-US 8-Bay Rac | AMD Ryzen Embedded V1500B 4-core/8-thread 2.2 GHz |
| QNAP TS-832PX-4G 8-Bay NAS | AnnapurnaLabs Alpine AL324 ARM Cortex-A57 quad-core 1.7GHz |
| QNAP TS-873A-8G 8 Bay NAS | AMD Ryzen V1500B quad-core 2.2 GHz |
| TERRAMASTER U8-500 Plus NAS 8- | Intel Core i7-1255U |
Factors to Consider When Choosing Top Rated 8 Bay Nas Storage System For Cad Workflows
Choosing the right 8 bay NAS for CAD workflows involves several key considerations. Beyond raw capacity, factors like network speed, hardware robustness, expandability, and ease of maintenance play critical roles. Understanding these elements can help prevent common pitfalls such as underestimating future storage needs or overpaying for features that won’t be used. The following sections highlight what to prioritize and how to avoid typical mistakes when investing in a NAS for demanding CAD projects.Performance and Network Speed
CAD workflows often involve large file transfers, making network throughput a top priority. Look for NAS units equipped with 10GbE or higher network interfaces to reduce bottlenecks, especially if multiple users access files simultaneously. Cheaper models with only 1GbE may suffice for small teams, but they can slow down productivity as file sizes grow. Consider the balance between network speed and CPU performance, as both impact data transfer rates and multitasking capabilities.
Hardware Build and Reliability
Reliability is paramount since CAD files are often critical and time-sensitive. Opt for models with enterprise-grade components, redundant power supplies, and solid build quality. While diskless options can save money upfront, they demand compatible, high-quality drives and a stable setup. Avoid models with questionable hardware or limited warranty coverage, as downtime can be costly in professional workflows.
Expandability and Scalability
Future growth is a key concern; select NAS systems that support additional drives or upgrades. Some models feature modular designs or multiple expansion ports, allowing you to increase storage or enhance performance down the line. Failing to consider expandability can lead to early obsolescence or costly migrations. Think about your projected storage needs over the next several years and choose accordingly.
Ease of Use and Support
Complex setups can hinder productivity, especially for teams without dedicated IT staff. User-friendly interfaces, straightforward setup procedures, and reliable customer support make a significant difference. Also, consider the availability of software updates and community resources. A system that’s difficult to configure or troubleshoot can slow down your project timelines and increase maintenance costs.
Cost and Long-Term Value
While high-end models offer superior performance and features, they come at a premium. Balance your budget against the expected workload and future needs. Investing in a slightly more expensive model with better hardware and support often pays off by reducing downtime and upgrade costs. Conversely, under-investing could lead to frequent bottlenecks or hardware failures, disrupting your CAD operations.
Frequently Asked Questions
Is a 10GbE network necessary for CAD workflows?
While a 10GbE network isn’t strictly necessary for smaller teams or less intensive CAD projects, it becomes increasingly valuable as file sizes grow and multiple users access data simultaneously. Higher network speeds reduce transfer times and improve overall productivity. If your team expects to handle large datasets regularly, investing in NAS units with 10GbE ports can significantly streamline workflows, though it also involves upgrading your network infrastructure.
Can I upgrade drives in a diskless NAS later on?
Yes, most diskless NAS systems are designed for easy drive installation and upgrades. This flexibility allows you to start with a basic configuration and expand storage as needed. However, ensure the NAS supports your intended drive types and capacities, and verify the upgrade process is straightforward. Planning for future drive replacements or expansions can help avoid costly migrations down the line.
What should I prioritize: hardware specs or software features?
Both aspects matter, but for CAD workflows, hardware specs often take precedence since large files and high-speed access demand powerful processors, ample RAM, and fast network interfaces. Software features like snapshots, remote access, and collaboration tools add convenience but won’t compensate for hardware bottlenecks. Focus on a system with robust hardware to ensure your CAD files are accessible and protected at all times.
Is a rackmount NAS better than a desktop model for CAD use?
Rackmount NAS units typically offer higher expandability, better cooling, and more robust hardware suited for demanding environments, making them ideal for enterprise CAD workflows. Desktop models are more compact and easier to deploy in small offices, but they may have limited expansion options. Your choice depends largely on your available space, scalability needs, and whether you plan to integrate the NAS into a larger server rack setup.
How important is vendor support and warranty for CAD storage systems?
Vendor support and warranty coverage are critical when your CAD operations rely on continuous, reliable access to large files. A responsive support team can resolve issues quickly, minimizing downtime. Extended warranties or on-site support provide extra peace of mind for mission-critical environments. Investing in reputable brands with established support networks can save time and money in the long run.
Conclusion
For demanding CAD workflows, the Synology DS1825+ emerges as the best overall choice thanks to its blend of performance, scalability, and user-friendly features. The QNAP TS-873A-8G is ideal for users needing maximum processing power and faster networking, making it suitable for intensive projects. Budget-conscious teams or those starting out with larger storage needs might find the Terramaster U8-500 a practical, flexible option. For enterprise environments, rackmount solutions with higher expandability are recommended, while small teams or individual professionals should prioritize ease of setup and support. Tailor your choice based on your current needs and future growth plans to ensure seamless CAD operations.
